Description
A powerful and compact Lithium Power Supply (LPS) built to provide power to 230V AC and 12V DC appliances without the complexities of additional equipment.
The LPS II 3000 model has a built-in 2kWh lithium-ion battery, 230V sine wave inverter, booster (charging from alternator), 400W MPPT charge controller (charging from solar panels), intelligent charger (charging from mains), relays etc.
This Lithium Power Supply offers flexible charging options. The built-in booster allows regeneration with 500W from any alternator. Connected to mains, the built-in intelligent charger regenerates with 750W. Connect solar panels directly - the built-in solar charge controller also allows regeneration from the sun with 400W.
For the LPS II remote control (supplied separately), see product code CP-RL1802. This remote allows the user to view state of charge, status and active jump start function.
For the LPS II mounting bracket (supplied separately), see product code CP-AL2001.
230 V/50 Hz output
- Peak: 5000W
- Power: 3000W
12 VDC output
- 60 Seconds: 350 A
- Continuously: 180 A
Built-in Li-Ion Battery
- Capacity: 2160 Wh (160 Ah)
- Efficient energy: 2kWh
Charging
Alternator: 500W / SC: 1000W
Solar panels: 400W
Mains: 750W
| Brand |
Clayton Power |
| Type |
Power Supply Units |
| Model |
CL2113 |
| Height Description |
256mm |
| Width |
277mm |
| Depth |
409mm |
| Weight |
27.5kg |
| Output |
230 V/50 Hz Output: Peak: 5000 W, Power: 3000 W |
| Wattage |
Charging: Alternator: 500 W / SC: 1000 W, Mains: 750 W, Solar Panels: 400 W |
| Operating Temperature |
-20°C - 50°C |
| Amps Description |
12V Output: 60 Seconds: 350 A, Continously: 180 A |
| Capacity Description |
Built-in Li-Ion Battery: 2160 Wh (160 Ah) |
| Country of Origin |
Denmark |
